Retro Round Top Vertical 2 column Radiator White & Anthracite
£166.64
In stock
Product Details
A Traditional style radiator with a contrasting Contemporary look. 2 columns, White or Anthracite are available from stock, Matt Black lead time 14-21 days. the Round Top has thicker oval tubes giving excellent output.
Round Top Vertical
Please note manufacturers outputs below are based on Delta T 70. For Delta T 50 divide by 1.549
| Overall Dimension
|
Pipe Centres mm | Wall to Pipe Centres mm | Wall Distance mm | Fuel Type | Heat Output @ Delta T 70
|
||
| Height mm | Width mm | Btu | Watts | ||||
| 1500 | 300 | 300 | 68 | 113 | C | 5031 | 1475 |
| 1500 | 370 | 370 | 68 | 113 | C | 6289 | 1844 |
| 1500 | 440 | 440 | 68 | 113 | C | 8547 | 2506 |
| 1500 | 510 | 510 | 68 | 113 | C | 8803 | 2582 |
| 1800 | 300 | 300 | 68 | 113 | C | 6036 | 1770 |
| 1800 | 370 | 370 | 68 | 113 | C | 7547 | 2213 |
| 1800 | 440 | 440 | 68 | 113 | C | 9055 | 2655 |
| 1800 | 510 | 510 | 68 | 113 | C | 10564 | 3098 |
| C: CENTRAL HEATING |
| For pipe center measurement including valves add 90mm +/- 5mm |
